CRISPR gRNA Design Tool
Our CRISPR guide RNA design engine is currently in active development. We're building a comprehensive platform for Cas9, Cas12a, and base editor guide design with AI-driven on-target and off-target scoring — all running on-premise for complete genomic data sovereignty.
Planned capabilities include:
SpCas9 · SaCas9 · StCas9 · Cas12a (AsCas12a, LbCas12a) · Base Editors (CBE, ABE)
Azimuth 2.0 · DeepCRISPR · CFD Off-Target · MIT Specificity
NGG · NGA · NAG · TTTV · Editing window optimisation
Ranked gRNAs with on-target scores, off-target reports & synthesis-ready oligos
In the meantime, our primer design tool handles all your PCR and qPCR assay design needs, and our CRISPR gRNA design guide covers the theory behind guide selection, efficiency prediction, and off-target minimisation.
How CRISPR-Cas9 Gene Editing Works
CRISPR-Cas9 is a programmable gene editing system adapted from the bacterial adaptive immune system. The Cas9 nuclease is guided to a specific genomic target by a single-guide RNA (sgRNA) that contains a 20-nucleotide spacer complementary to the target DNA sequence. For SpCas9, the target must be immediately upstream of a PAM sequence (NGG) — a short protospacer-adjacent motif required for Cas9 recognition and cleavage. Once bound, Cas9 creates a double-strand break (DSB) that the cell repairs through either non-homologous end joining (NHEJ), which creates small insertions or deletions (indels) that disrupt the gene, or homology-directed repair (HDR), which uses a repair template to introduce precise edits. The typical workflow involves: Target selection → gRNA design → gRNA synthesis and RNP complex formation → Delivery into cells → DNA cleavage and repair → Screening and validation.
gRNA Design Rules for Successful CRISPR Experiments
| Parameter | Recommendation | Why It Matters |
|---|---|---|
| Spacer length | 20 nt | Standard length for SpCas9 recognition and specificity |
| GC content | 40-70% | Higher GC improves R-loop stability and cleavage efficiency |
| PAM sequence | NGG (for SpCas9) | Required for Cas9 recognition — no cleavage without PAM |
| Off-target matches | ≤3 mismatches tolerated | Partial complementarity can lead to unintended edits at off-target sites |
| Position in gene | Early exons (exon 1-3) | Frameshift mutations in early exons maximise knockout efficiency |
Avoid: Poly-T runs (TTTT) — these act as RNA polymerase III termination signals and truncate gRNA transcription. Also avoid homopolymer runs longer than 4 bases which increase off-target effects.
Understanding CRISPR Off-Target Effects
Off-target effects occur when a gRNA binds to genomic sites with partial sequence complementarity, leading to unintended DNA cleavage. This is a major concern in therapeutic applications where off-target edits could disrupt essential genes or create oncogenic mutations. Computational scoring tools like the CFD (Cutting Frequency Determination) score and MIT specificity score predict off-target potential by analysing sequence complementarity, mismatch position, and bulges. The CFD score accounts for mismatches across the entire spacer, while the MIT score focuses on seed region (positions 1-12) complementarity. Both scores range from 0-100, with higher values indicating greater specificity.
| Mitigation Strategy | Effectiveness | Trade-off |
|---|---|---|
| High-fidelity Cas9 variants (eSpCas9, SpCas9-HF1) | 80-95% off-target reduction | May reduce on-target efficiency by 10-30% |
| Truncated gRNAs (17-18 nt) | Moderate reduction | Reduced on-target activity at some loci |
| Paired nickase approach (Cas9n) | High specificity (dual nicks required) | Requires two gRNAs per target, increases complexity |
| Algorithmic off-target prediction | Essential first pass | Requires experimental validation — no algorithm is perfectly predictive |
Get Early Access
Join the waitlist for priority access when we launch the CRISPR gRNA design tool.
No spam. Unsubscribe anytime.
CRISPR gRNA Design Capabilities
Cas9 gRNA Design
Design 20 nt guide RNAs with NGG PAM recognition. On-target efficiency scoring, off-target CFD scoring, and synthesis-ready oligo output.
- SpCas9, SaCas9, StCas9 variants
- NGG, NGA, NAG PAM support
- Azimuth 2.0 on-target scoring
- CFD off-target scoring (3-mismatch)
Cas12a (Cpf1) Design
Design 23-25 nt crRNAs with TTTV PAM recognition for Cas12a (Cpf1) nucleases. Supports both wild-type and enhanced variants.
- AsCas12a and LbCas12a
- TTTV PAM recognition
- 5' TTTV-anchored design
- DeepCRISPR on-target score
Base Editor Guides
Design guides for cytosine and adenine base editors with editing window placement optimisation and bystander editing prediction.
- CBE and ABE support
- Editing window (positions 4-8)
- Bystander editing prediction
- Protospacer-adjacent motif check
Off-Target Analysis
Genome-wide off-target prediction with CFD scores, mismatch tolerance, and exonic/intronic target classification.
- Genome-wide BLAST search
- CFD and MIT scoring
- Exonic, intronic, intergenic classification
- Top 10 off-target report
Learn CRISPR gRNA Design
Read our comprehensive guide covering Cas9, Cas12a, and base editor guide design with efficiency prediction and off-target minimisation.
Read CRISPR Guide →CRISPR Guide RNA Design Tool — Inputs & Outputs
VigyanLLM is an autonomous CRISPR guide RNA design tool that utilizes AI algorithms for CRISPR guide RNA identification and off-target scoring. Unlike standard web CRISPR tools, it runs entirely on your local infrastructure via Docker, enabling genome-scale CFD scoring without transferring proprietary genomic data to external servers.
| Input | Output |
|---|---|
| Target DNA sequence (FASTA format) | Ranked guide RNA sequences with PAM annotation |
| Target gene symbol or genomic locus | Doench 2016 on-target efficiency scores |
| Reference genome (for off-target analysis) | CFD off-target mismatch scores against genome database |
Frequently Asked Questions About CRISPR Guide RNA Analysis
Everything you need to know about using this tool
How do I design CRISPR guide RNA for genome editing?
VigyanLLM's CRISPR tool (currently in development) will accept a target DNA sequence or gene symbol, identify all PAM sequences, rank guide RNAs by on-target efficiency score using Azimuth 2.0, and predict genome-wide off-target effects using CFD scoring. Design synthesis-ready oligos with the required adapters for your preferred delivery method.
What is guide RNA (gRNA) and how is it designed?
Guide RNA (gRNA) is a synthetic RNA molecule that directs the Cas9 nuclease to a specific genomic target. It consists of a 20-nucleotide spacer sequence complementary to the target DNA and a scaffold that binds Cas9. Design rules include: 20 nt spacer length, 40-70% GC content, target upstream of an NGG PAM sequence, and minimal off-target matches across the genome.
How does VigyanLLM score CRISPR gRNA efficiency?
VigyanLLM uses validated scoring algorithms including Azimuth 2.0 for on-target efficiency prediction, which considers nucleotide preferences at each position in the guide, GC content, and thermodynamic stability. Off-target scoring uses the CFD (Cutting Frequency Determination) algorithm that accounts for mismatch position sensitivity and bulges.
How does VigyanLLM check for CRISPR off-target effects?
Off-target analysis searches the genome for sequences with partial complementarity to the gRNA spacer, allowing up to 3 mismatches and 1 DNA bulge. Each potential off-target site is scored using CFD and MIT specificity scores that weight mismatches differently based on their position within the guide. Results include a ranked list of the top potential off-target sites.
What PAM sequences does VigyanLLM CRISPR tool support?
VigyanLLM supports PAM sequences for multiple Cas variants: SpCas9 (NGG), SaCas9 (NNGRRT), Cas12a/Cpf1 (TTTV), and expanded PAM variants. Users can also specify custom PAM sequences for engineered Cas variants. The tool automatically detects eligible PAM sites in the target sequence and designs guides for each validated PAM type.
Can I design primers for CRISPR verification PCR?
Yes, for CRISPR editing verification you need primers flanking the cut site to amplify the edited locus for Sanger sequencing or T7E1 mismatch cleavage assay. VigyanLLM can design these verification primers after gRNA selection, with amplicon size optimized for Sanger sequencing read length (400-700 bp including the cut site).
Does VigyanLLM support base editing gRNA design?
Base editing guides require the target base to be positioned within the editing window of the deaminase enzyme (typically positions 4-8 of the spacer for APOBEC-based cytosine editors). VigyanLLM will support CBE and ABE base editor guide design with editing window placement optimization and prediction of bystander editing events.
How to design pegRNA for prime editing?
Prime editing uses a pegRNA that combines a guide RNA with a reverse transcriptase template encoding the desired edit. Design requires determining optimal primer binding site (PBS) length (typically 10-15 nt), reverse transcriptase template (RTT) length (10-30 nt), and nicking sgRNA positioning. This capability is planned for a future VigyanLLM update.
Can VigyanLLM design multiple gRNAs for multiplex CRISPR?
Yes, VigyanLLM will support multi-target gRNA design by processing each target independently and then combining results. The tool checks for cross-homology between guides to minimize off-target effects and supports tRNA-gRNA array design for polycistronic expression from a single promoter.
How to design gRNAs for gene knockout experiments?
For gene knockout, target early coding exons (exon 1-3) upstream of the protein functional domains. Aim to create frameshift indels that disrupt all transcript isoforms. Avoid the first 50 bp after the start codon and the last 50 bp before the stop codon. Design 3-4 gRNAs per target and test each experimentally since efficiency varies by locus.
How to design gRNAs for CRISPR knock-in experiments?
For knock-in experiments, select a cut site within 10-20 bp of the desired insertion point. Design the HDR repair template with homology arms of 300-800 bp on each side, silent mutations to prevent re-cutting after repair, and the donor sequence flanked by homology arms. Check for SNPs and repeat elements in the homology arm regions.
What is the difference between sgRNA and gRNA?
sgRNA (single guide RNA) is an engineered fusion of the CRISPR RNA (crRNA, which contains the 20 nt spacer) and the trans-activating crRNA (tracrRNA, which binds Cas9) into a single synthetic RNA molecule. Traditional gRNA refers to the two-component system of separate crRNA and tracrRNA. Most modern CRISPR systems use sgRNA for simplicity.
Does VigyanLLM provide CRISPR delivery recommendations?
VigyanLLM provides general guidance on CRISPR delivery methods including: plasmid transfection (standard for cell lines), RNP complex delivery (lower off-target, suitable for primary cells), viral delivery via AAV or lentivirus (for in vivo applications), and mRNA electroporation (transient expression, minimal DNA integration risk).
How do I plan a complete CRISPR experiment using VigyanLLM?
The complete CRISPR workflow: (1) Select target gene and identify early coding exons, (2) Design gRNAs with on-target and off-target scoring, (3) Choose delivery method (plasmid, RNP, or viral), (4) Order gRNAs as synthetic oligos or cloned into expression vectors, (5) Transfect cells and harvest DNA after 48-72 hours, (6) Verify editing by Sanger sequencing or T7E1 assay using flanking primers.
What is the difference between CRISPR-Cas9 and Cas12a (Cpf1)?
Cas9 requires a 20 nt gRNA and NGG PAM, creates a blunt double-strand break 3 bp upstream of the PAM. Cas12a requires a 23-25 nt crRNA and TTTV PAM, creates a staggered cut with 5 bp overhangs 18-23 bp downstream of the PAM. Cas12a is smaller (1300 vs 1600 aa) and has intrinsic RNase activity for processing its own crRNA arrays.
